Compact round base design.
Bronze Plated.
Manual chain release.
Chain counter pre-setting as standard.
Heavy duty rated IP67 electric motor.
Anodised marine aluminium gearbox.
.png)
.png)
Complete Windlass.
Chain gypsy.
Dual Direction Solenoid pack.
Winch handle.
CD/ Instruction Manual.
| Construction | Bronze | ||
|---|---|---|---|
| Motor Size | 500W | 800W | 1000W |
| Power Supply (V) |
12 | 12 | 12 |
| Maximum Linea Load (kg) | 630 | 700 | 900 |
| Lift Working Load (kg) | 95 | 100 | 125 |
| Amps Work Load (A) | 60 | 110 | 125 |
| Line Speed (m/min) | 23 | 25 | 18 |
| Max Line speed (m/min) | 26 | 28 | 30 |
| Net Weight Low Profile (kg) | 10 | 13 | 16 |
| Net Weight with drum (kg) | 11 | 14 | 17 |
| Control Box | Included | Included | Included |
| Construction | Bronze Plated | Bronze Plated | Bronze Plated |
|---|---|---|---|
| Motor Size | 500W | 800W | 1000W |
| Chain Size |
1,125.89 €
Sale Price 1,013.03 € |
1,220.50 €
Sale Price 1,098.45 € |
1,400.27 €
Sale Price 1,260.25 € |
| 6mm chain or 10/12mm 3 strand rope |
636206 |
636433 |
|
| 8mm chain or 12mm 3 strand rope |
636700 |
636432 |
636701 |
| Construction | Bronze Plated |
|---|---|
| Motor Size | 800W |
| Chain Size |
1,305.65 €
Sale Price 1,175.09 € |
| 8mm chain or 12mm 3 strand rope |
636702 |
