Lofrans Razza Windlass

Marine AISI 316L Stainless Steel construction

Automatic free fall available (optional).

Manual chain release.

Rope chain management by the spring load arm.

Heavy duty rated IP67 motor cover.

QR code card for Instruction Manual

Handle

Construction	316L Stainless Steel
Motor Size	500W	800W
Power Supply	12v	12v
Maximum Pull (kg)	630	900
Working Load (kg)	95	125
Amps at Working Load	65	80
Line Speed at Working Load (m/min)	18	20
Max Line Speed (m/min)	24	25
Net Weight (kg)	11	11

Chain and Rope
Size

Motor

Part

	6mm
	10-12mm 3 Strand

500w

1,362.42 €
Sale Price
1,226.18 €

2813001

	8mm
	12mm 3 Strand

500w

1,362.42 €
Sale Price
1,226.18 €

2813021

	6mm
	10-12mm 3 Strand

800w

1,419.19 €
Sale Price
1,277.27 €

2833001

	8mm
	12mm 3 Strand

800w

1,419.19 €
Sale Price
1,277.27 €

2833021
