Top holding power Delta Type anchor
Hot-dip Galvanized
Equipped with a lead-filled tip to ensure stability and consistent recovery
Available in 10 different sizes
 |
 |
| Code | Weight (kg) | A mm | B mm | C mm | D mm | E mm |
|---|---|---|---|---|---|---|
| 75460 | 4kg | 514 | 230 | 8 | 210 | 387 |
| 75461 | 6kg | 593 | 265 | 10 | 243 | 450 |
| 75462 | 10kg | 695 | 310 | 12.5 | 282 | 526 |
| 75463 | 16kg | 812 | 362 | 12.5 | 328 | 614 |
| 75464 | 20kg | 877 | 392 | 16 | 357 | 663 |
| 75465 | 25kg | 945 | 415 | 16 | 387 | 713 |
| 75466 | 32kg | 1023 | 453.5 | 20 | 435 | 833 |
| 75467 | 40kg | 1099 | 489 | 20 | 435 | 833 |
| 75468 | 50kg | 1175 | 523 | 20 | 479 | 890 |
| 75469 | 63kg | 1270 | 567 | 22 | 508 | 963 |
| Code | Description | Price |
|---|---|---|
| 75460 | Lofrans Anchor ALPHA 4kg |
47.31 €
|
| 75461 | Lofrans Anchor ALPHA 6kg |
66.24 €
|
| 75462 | Lofrans Anchor ALPHA 10kg |
104.07 €
|
| 75463 | Lofrans Anchor ALPHA 16kg |
160.85 €
|
| 75464 | Lofrans Anchor ALPHA 20kg |
198.68 €
|
| 75465 | Lofrans Anchor ALPHA 25kg |
245.99 €
|
| 75466 | Lofrans Anchor ALPHA 32kg |
312.22 €
|
| 75467 | Lofrans Anchor ALPHA 40kg |
387.91 €
|
| 75468 | Lofrans Anchor ALPHA 50kg |
482.52 €
|
| 75469 | Lofrans Anchor ALPHA 63kg |
605.52 €
|
